1. VI curve analysis, also known as ASA, does not involve circuit principle and does not require the circuit to be in working state, so it can be used for fault detection of circuit boards that are separated from equipment (without online detection) without drawing data; It is absolutely forbidden to carry out electrification and measure the undischarged capacitance. Since the circuit board does not need to be powered, the circuit board is relatively .2. It does not involve the functions of the devices on the circuit board, so no matter what type of devices the circuit is composed of, digital, analog, digital analog mixed, functional known, unknown (such as dedicated, programmable), etc., it can be tested; It is tested by circuit node (device pin), and is basically not limited by the packaging of components on the circuit board.3. As a single device can be regarded as the simplest circuit board, ASA technology can also be used to detect the quality of -scale, complex or unknown integrated devices. In fact, due to limited conditions, ASA is the only way for many users to detect such devices. In addition, ASA is convenient and intuitive when it is used to detect the function of discrete components.4. VI and multimeter resistance type, but the multimeter resistance voltage is low, and this instrument uses AC signal to excite circuit nodes. Because the amplitude and frequency are adjustable, the amplitude close to the working voltage can be used to excite, and the measured graph is more real.5. The fault node can be found through comparison. Due to the limited current applied to the components, this technology will not affect or damage any components. ASA has many advantages, and it has been proved to be a fast and effective fault diagnosis technology.Features: 1. with 1.3 inch OLED display2. Built-in battery, 3000mAh3. 4-gear voltage adjustable(0.6V 4V 8V 16V), 4. 4 test frequency(60Hz 400Hz 2000Hz).5. Curve movement: Yes6. Scan function: Yes7. True dual channel: Yes8. Simultaneous display: Yes9. Program control: YesNote: Discharge before measurement, otherwise the instrument will be damaged.Material: plasticcolour: As ShownPackage Contents: 1 x VI Curve Tester2 x BNC cable2 x Test leads1 x USB Power cableOnly the above package content, other products are not included.Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
